Product Introduction
|
Name |
LW550X1650-N | LW550X2200-N |
|
Drum diameter |
550 mm / 22 in | 550 mm / 22 in |
|
Drum length |
1650 mm / 65 in | 2200 mm / 87 in |
|
Maximum speed |
3200 rpm | 3000 rpm |
|
Standard speed |
2500 rpm | 2300 rpm |
|
Separating factor |
3154 | 2772 |
|
Handling capacity |
5-35 m3/h | 5-40 m3/h |
|
Main motor power |
55 kW | 55 kW |
|
Auxiliary motor power |
22 kW | 22 kW |
|
Size |
3885 x 1350 x 1600 mm / 153 x 53 x 63 in | 5180 x 1270 x 1440 mm / 204 x 50 x 57 in |
|
Weight |
4000 Kg | 6000 Kg |
